Features
MILC™
AudioControls MILCTM (Maximum Input Level Control) patent-pending source clip detection circuit. MILCT™ calculates when the waveform of an incoming audio signal is clipping, and if it is, the LED will fulfill its prime objective and shine forth, aiding in precise level matching control.
Option Port
The built-in Option Port on the DM-810 is the future of car audio and allows hi-res streaming and DSP programming directly into the DSP using the AC-BT24 Bluetooth Streamer/Programmer. It also opens up future proprietary connections for additional inputs, controllers and interface solutions. Watch this space for future Option Port expansion options.
DM Smart DSP
• Connect your laptop to the DM-608 using AudioControl’s DM Smart DSP app, a fully featured Matrix DSP Interface designed to give you instant and clear control over every aspect of your processor.
• Route any input to any output, adjust gain, delay and polarity then precisely tune the DM-608 using a 30 band EQ. High-pass, low-pass and band-pass can be set up for any output using 12 or 24 dB/octave Linkwitz-Riley crossovers.
• For OEM integration, take advantage of the input and output RTAs, available for every input and output, to easily identify and sum factory speaker signals.
• With a clear GUI and intuitive workflow, AudioControl’s DM Smart DSP will take the guesswork out of tuning your system to your exact specifications.
• Route any input to any output, adjust gain, delay and polarity then precisely tune the DM-608 using a 30 band EQ. High-pass, low-pass and band-pass can be set up for any output using 12 or 24 dB/octave Linkwitz-Riley crossovers.
• For OEM integration, take advantage of the input and output RTAs, available for every input and output, to easily identify and sum factory speaker signals.
• With a clear GUI and intuitive workflow, AudioControl’s DM Smart DSP will take the guesswork out of tuning your system to your exact specifications.
Specifications
General
Frequency Response
20 Hz to 24 kHz Hz
THD
0.01 %
Electronic Features
• Power Supply: High Headroom PWM Switching
• Current Draw: 1A
• Recommended Fuse Rating: 3A
• Current Draw: 1A
• Recommended Fuse Rating: 3A
Additional Information
• Input and Output RTA for precise and informed tuning
• GTO™ Signal Sensing
• MILC™ Clip Detection
• AccuBASS®
• Signal Summing
• Signal Delay
• 12 and 24 dB/octave crossovers
• 30 band equalizer
• Optional ACR-3 remote for preset recall and level control
• Optional AC-BT24 Bluetooth Streamer/Programmer
• DM Smart DSP app available in downloads for Mac/PC
• 12 VDC Remote In
• 12 VDC Remote Out (always active when unit is on)
• Input:
• Preamp Input Channels: 6
• Digital Inputs: 1 x Toslink and Coax
• Input Impedance Preamp / Speaker-level: 20 ohms / 7 ohms
• Outputs:
• Preamp Outputs Channels: 8
• Maximum Output Level: 10 Vrms
• Output Impedance: 150 ohms
• GTO™ Signal Sensing
• MILC™ Clip Detection
• AccuBASS®
• Signal Summing
• Signal Delay
• 12 and 24 dB/octave crossovers
• 30 band equalizer
• Optional ACR-3 remote for preset recall and level control
• Optional AC-BT24 Bluetooth Streamer/Programmer
• DM Smart DSP app available in downloads for Mac/PC
• 12 VDC Remote In
• 12 VDC Remote Out (always active when unit is on)
• Input:
• Preamp Input Channels: 6
• Digital Inputs: 1 x Toslink and Coax
• Input Impedance Preamp / Speaker-level: 20 ohms / 7 ohms
• Outputs:
• Preamp Outputs Channels: 8
• Maximum Output Level: 10 Vrms
• Output Impedance: 150 ohms
Dimensions
Width
9.4 inch(es) / 23.88 cm
Height
1.6 inch(es) / 4.06 cm
Depth
5.7 inch(es) / 14.48 cm
Weight
2.4 lb(s) / 1.09 kg
