Specifications
General
Maximum Power
300 W
RMS Power
100 W
Sensitivity
96 dB
Frequency Response
40 Hz - 23,000 Hz
Impedance
4 ohms
Type
3-way
Mounting Depth
3.19 inch(es) / 8.1 cm
Features
Additional Information
• Horn Loaded Tweeter: 40 mm horn loaded dome tweeter contributing to its incredible efficiency of up to 96dB SPL
• Acoustics lens applied to the tweeter, specifically designed to increase dispersion in the high frequency range
• PEI (Polyethylene injected) supertweeter employed to strengthen emission of very high frequency ranges otherwise affected by off-axis positioning common to rear deck installations
• Water-repellent treated paper cone, featuring a profile developed with FEM (Finite Element Method) simulation technology and optimized with the Klippel Scan Vibrometer
• Pure copper mobile voice coil, wound on Kapton former, for better thermal and mechanical capacity
• TPU (Thermoplastic Polyurethane) surround, featuring the exclusive shallow "Triple Wave" profile, for maximum excursion linearity
• Polycotton spider material ensuring reliable performance and linear response to musical transients
• Acoustics lens applied to the tweeter, specifically designed to increase dispersion in the high frequency range
• PEI (Polyethylene injected) supertweeter employed to strengthen emission of very high frequency ranges otherwise affected by off-axis positioning common to rear deck installations
• Water-repellent treated paper cone, featuring a profile developed with FEM (Finite Element Method) simulation technology and optimized with the Klippel Scan Vibrometer
• Pure copper mobile voice coil, wound on Kapton former, for better thermal and mechanical capacity
• TPU (Thermoplastic Polyurethane) surround, featuring the exclusive shallow "Triple Wave" profile, for maximum excursion linearity
• Polycotton spider material ensuring reliable performance and linear response to musical transients
Dimensions
Width
9.37 inch(es) / 23.8 cm
Height
6.38 inch(es) / 16.21 cm
Depth
3.78 inch(es) / 9.6 cm
Weight
2.69 lb(s) / 1.22 kg
