Specifications
General
Total Max Power
1000 W
RMS Power
600 W
Number of Channels
2
Amplifier Class
D
Load Impedance Capability
2 ohms
Crossover Frequencies
• Crossover (-12 dB/ Oct) Variable High-Pass: 40Hz-400Hz
• Crossover (-12 dB/ Oct) Variable Low-Pass: 40Hz-400Hz
• Crossover (-12 dB/ Oct) Variable Low-Pass: 40Hz-400Hz
Total Harmonic Distortion
0.5%
Additional Information
• RMS Power(2 ohms): 300 W x 2
• RMS Power (4 ohms): 200 W x 2
• MS Bridge (mono 4 ohms): 600 W x 1
• Updated High-Efficiency Full Range Digital Topology
• Enhanced Power IR Digital Chipset
• Conformal-Coated 4-layer PCB
• Remote Turn On Configurator - REM/DC/VOX
• Boosted RFI (Radio Frequency Interference) Rejection
• Compact Matching Heatsink Platform Dimensions
• Accepts HI and LO Level Input Up To 12V
• Water-Resistant
• RMS Power (4 ohms): 200 W x 2
• MS Bridge (mono 4 ohms): 600 W x 1
• Updated High-Efficiency Full Range Digital Topology
• Enhanced Power IR Digital Chipset
• Conformal-Coated 4-layer PCB
• Remote Turn On Configurator - REM/DC/VOX
• Boosted RFI (Radio Frequency Interference) Rejection
• Compact Matching Heatsink Platform Dimensions
• Accepts HI and LO Level Input Up To 12V
• Water-Resistant
Dimensions
Width
4.02 inch(es) / 10.21 cm
Height
1.4 inch(es) / 3.56 cm
Depth
7.7 inch(es) / 19.56 cm
Warranty
Warranty
1 year
