Features
Environmentally Tough with Stylish Looks
Its single DIN chassis and face make it an excellent replacement system for smaller or older boats, while its upscale design fits right in with today’s highly stylized boat consoles and cabins. Designed for the boat environment, the two-line LCD display is able to show the information you need during day or night usage while the connectors have a protective cover to inhibit corrosion and damage.
Clearly Visible High Contrast LCD Display
The 13-digits 2-line display on the M508 allows numbers and characters to be displayed clearly - in all lighting conditions. Whether you want to know what song is playing on satellite radio or just need to know the time, it’s always easy to see.
High Quality Bluetooth Audio Streaming powered by Qualcomm® aptX™ and Hands-free Calling
Enjoy Bluetooth audio streaming with improved quality thanks to aptX codec support. This technology improves audio quality when listening to compressed audio over Bluetooth in a way that doesn’t degrade audio quality or cause latency, and reproduces the full audio bandwidth for quality sound on the waves.With Hands-free Profile, enjoy placing and taking calls through your radios sound system when connected to an optional external microphone.
* Depending on mobile phone.
* Please see our website for details of compatible Bluetooth mobile phones.
Superior iPhone, iPod, and iPad Connectivity
Enjoy the familiar controls of your iOS device with items such as album, artist and song list displayed on-screen. Utilize the search function to quickly access desired music. A simple control mode allows you to operate the source unit using the controls on your device.
* For audio playback, please use the USB cable provided with your iPod and iPhone and iPad
Front AUX Input for Convenient Connection
With AUX input connectors right on the front of the unit, it’s extremely easy to hookup an external audio source for enjoyment through your boat’s audio system.
Dual Zone Audio with Fixed Output
With this function, it is possible to split your boat into two discrete zones to enjoy different volume levels of entertainment. For instance, the bow can be tuned-in to a higher volume level for enjoyment in the wind while the stern can enjoy the music at a lower volume to accommodate conversations. Volume levels from the fixed zone are controlled by an optional external volume control device. This is ideal for separate areas such as salons, wakeboard towers, and open bows.
SiriusXM™ Satellite Radio with Optional Tuner (SXV100 / 200 / 300)
Connect, control and enjoy all of SiriusXM Satellite Radio's offerings on your boat. Whether listening to commercial-free music, sports talk or news radio, all available 24/7, bring the hottest in entertainment on-board and on your journey.
Enjoy interactive Pandora internet radio anytime anywhere
Pandora internet radio is at home in your boat. The source unit’s Pandora feature works together with the Pandora app on your smart device. Play songs while you feedback a “thumbs up” or “thumbs down” which is reflected in future selections. The Pandora app lets you bookmark Artists/Songs or even create your own station to customize your marine music experience.
3-Band EQ For Customizable Sound
In addition to providing 3 preset equalization patterns — BASS BOOST, IMPACT, and EXCITE — Clarion’s 3-Band EQ even lets you freely customize the level and range of the bass, midrange and treble portions of each pattern. You can tune the sound to your liking, depending on the category of music, for a more personalized and fulfilling listening experience.
Low Pass Filter for Subwoofer
Switching on the Low Pass Filter (LPF) will send only the low frequency range through specified outputs to ensure superb performance when connected to a subwoofer.
Marine Wired Remote Compatible (MW1/MW2/MW3/MW4/MF2)
Remote control sold separately.
Additional Features
8-Channel 4-Volt RCA Outputs Make It Easy to Expand and Upgrade
Equipped with 8-channel line outputs, you have independent controls over each channel for amplification. Front and rear speakers will retain fader and balance control while the subwoofer levels can be adjusted from the source unit for on the fly adjustments.
Specifications
General
Maximum Power
200 W
RMS Power
18 W
Number of Channels
8
DIN
1
Volume Control
Rotary
CD
No
DVD
No
USB Input
Yes
Tape Deck
No
Navigation
No
LCD Screen
No
Motorized LCD Screen
No
Inputs/Outputs
Front Speaker Preouts
Yes
Front Speaker Preouts Voltage
4 V
Back Speakers Pre-Outs
Yes
Back Speakers Preouts Voltage
4 V
Subwoofer Pre-Outs
Yes
Subwoofer Preouts Voltage
4 V
Aux Inputs
Yes
Compatibility
Bluetooth
Built-In
XM/Sirius Radio
Yes
HD Radio Ready
Yes
Equalizer
Low-Pass Crossover
80 / 120 / 180
Accessories
Remote Control
No
Dimensions
Width
7.13 inch(es) / 18.1 cm
Height
2 inch(es) / 5.08 cm
Depth
6.5 inch(es) / 16.51 cm
Warranty
Warranty
1 Year
UPC
UPC#
729218022429
