Features
Engineered to Withstand Water and Salt
Water and salt can be a marine source unit's worst nightmare. Our M608 source unit is IP55 tested and certified to provide you the best in water intrusion and salt water protection in its class, at the front panel where it’s most exposed to the elements. Internally, rubber gaskets stop water in its tracks and integrated drainage channels keep water out, with an IPX3 tested and certified stainless steel chassis for protection even if water manages to seep into the console.
Audio that’s Built for Marine Environments and Matches the Design of All Cabins
Its single DIN chassis and face make it an excellent replacement system for smaller or older boats, while its upscale design fits right in with today’s highly stylized boat consoles and cabins. The two-line LCD display is able to show the information you need.
Clearly Visible High Contrast LCD Display
The 13-digits 2-line display on the M508 allows numbers and characters to be displayed clearly - in all lighting conditions. Whether you want to know what song is playing on satellite radio or just need to know the time, it’s always easy to see.
Bluetooth High Quality Streaming powered by Qualcomm® aptX™ audio
Enjoy Bluetooth audio streaming with improved quality thanks to aptX codec support. This technology improves audio quality when listening to compressed audio over Bluetooth in a way that doesn’t degrade audio quality or cause latency, and reproduces the full audio bandwidth for quality sound while out on the water.
* Depending on mobile phone.
Superior iPhone®, iPod®, and iPad® Connectivity
Enjoy the familiar controls of your iOS device with items such as album, artist and song list displayed on-screen. Utilize the search function to quickly access desired music. A simple control mode allows you to operate the source unit using the controls on your device.
4 Zone Audio Volume Control
Since it is possible to control up to four independent audio zones on the same vessel, people can enjoy listening to the same source in the cabin, in the cockpit and on the deck with the freedom to adjust volume based on their preferences.
SiriusXM™ Satellite Radio with Optional Tuner (SXV100 / 200 / 300)
Connect, control and enjoy all of SiriusXM Satellite Radio's offerings on your boat. Whether listening to commercial-free music, sports talk or news radio, all available 24/7, bring the hottest in entertainment on-board and on your journey.
Enjoy interactive Pandora internet radio anytime anywhere
Pandora internet radio is at home in your boat. The source unit’s Pandora feature works together with the Pandora app on your smart device. Play songs while you feedback a “thumbs up” or “thumbs down” which is reflected in future selections. The Pandora app lets you bookmark Artists/Songs or even create your own station to customize your marine music experience.
Global Radio Tuner with Weather Band
The built-in multi-band tuner supports reception of radio stations just about anywhere in the world — which is nice when you’re sailing around the globe or just across the gulf. And with Weather Band you’ll always have the latest weather updates, including automatic reception of emergency weather information to keep your voyage as smooth as possible.
3-Band EQ For Customizable Sound
In addition to providing 3 preset equalization patterns — BASS BOOST, IMPACT, and EXCITE — Clarion’s 3-Band EQ even lets you freely customize the level and range of the bass, midrange and treble portions of each pattern. You can tune the sound to your liking, depending on the category of music, for a more personalized and fulfilling listening experience.
Built-in High Pass and Low Pass Filters
The internal High Pass and Low Pass Filters allow your music to be played at the precise levels that they were meant to be heard. Enjoy bass with more muscle and highs with more clarity..
Marine Wired Remote Compatible (MW1/MW2/MW3/MW4/MF2)
Remote control sold separately.
Additional Features
8-Channel 4-Volt RCA Outputs Make It Easy to Expand and Upgrade
Equipped with 8-channel line outputs, you have independent controls over each channel for amplification. Front and rear speakers will retain fader and balance control while the subwoofer levels can be adjusted from the source unit for on the fly adjustments.
NMEA 2000 Connectivity with Optional Interface Module (Clarion MW6)
Clarion marine source units are able to be seamlessly added to a boat's onboard NMEA 2000 network, enabling control of Clarion source units directly from the boat's Multi-Function Display (MFD) device. Clarion marine source units allow boaters to control various audio system functions, including source and track selection, play / pause, and more, directly from their MFD. Additionally, two-way communication between a Clarion source unit and MFD allows source selection, song / track / album title, radio frequency and more to display on the MFD interface.
Specifications
General
Maximum Power
200 W
RMS Power
18 W
THD and Frequency
20 Hz - 20,000 Hz
Number of Channels
4
DIN
1
Volume Control
Rotary
CD
No
DVD
No
USB Input
Yes
Tape Deck
No
Navigation
No
LCD Screen
Yes
Motorized LCD Screen
No
Additional Information
• IP55
• Salt-Water Resistant
• Salt-Water Resistant
Inputs/Outputs
Front Speaker Preouts
Yes
Front Speaker Preouts Voltage
4 V
Back Speakers Pre-Outs
Yes
Back Speakers Preouts Voltage
4 V
Subwoofer Pre-Outs
Yes
Subwoofer Preouts Voltage
4 V
Aux Inputs
Yes
Compatibility
Bluetooth
Built-In
MP3
Yes
WMA
Yes
XM/Sirius Radio
Yes
HD Radio Ready
Yes
iPod Connection
Yes
Accessories
Remote Control
No
Detachable Faceplate
No
Dimensions
Width
7.65 inch(es) / 19.43 cm
Height
0.94 inch(es) / 2.39 cm
Depth
3.4 inch(es) / 8.64 cm
Warranty
Warranty
1 Year
UPC
UPC#
0729218022429
