Specifications
General
RJ45
2
USB
1
Inputs
• Stereo analog (3.5mm)
• Digital Coaxial
• Digital Coaxial
Outputs
• HDMI
• Stereo analog (3.5mm)
• Digital Coaxial
• IR x 6
• Serial x 3 (shared with IR out 1-3)
• Stereo analog (3.5mm)
• Digital Coaxial
• IR x 6
• Serial x 3 (shared with IR out 1-3)
Additional Information
• Three audio outputs—one HDMI, one stereo analog, and one digital coax—distribute up to three simultaneous, high-resolution audio streams from native streaming services, AirPlay-enabled devices, and local music.
• Integrated music server with native support for popular streaming services, including Deezer, Pandora, Rhapsody, Tidal, and TuneIn
• Elegant on-screen experience for easy access to entertainment and the entire home.
• PoE+ provides power and network connectivity over a single CAT5/CAT6 cable
• Integrated Wireless-N and ZigBee with external antennas simplify installation while delivering high-performance connectivity
• USB port enables connection to external hard drives for easy access to music content.
• Integrated music server with native support for popular streaming services, including Deezer, Pandora, Rhapsody, Tidal, and TuneIn
• Elegant on-screen experience for easy access to entertainment and the entire home.
• PoE+ provides power and network connectivity over a single CAT5/CAT6 cable
• Integrated Wireless-N and ZigBee with external antennas simplify installation while delivering high-performance connectivity
• USB port enables connection to external hard drives for easy access to music content.
Compatibility
Security
WEP, WPA, and WPA2
Dimensions
Width
8.75 inch(es) / 22.23 cm
Height
1.25 inch(es) / 3.18 cm
Depth
5.87 inch(es) / 14.92 cm
Weight
1.61 lb(s) / 0.73 kg
Shipping Dimensions
Weight
2.76 lb(s) / 1.25 kg
