Specifications
General
Maximum Power
700 W
RMS Power
350 W
Sensitivity
86 dB
Impedance
4 ohms
Mounting Diameter
9.2 inch(es) / 23.37 cm
Mounting Depth
5.1 inch(es) / 12.95 cm
Features
Additional Information
• Extremely stiff Kevlar / paper sandwich cone
• Oversized voice coils with an impressive winding height for maximum electrical power handling and high linear excursion
• Large magnet systems for low Qts, ideal for compact bass-reflex enclosures
• Double-vented voice long-stroke coils for minimized compression effects
• Aluminum diecast basket with diamond cut surround mounting ring
• Solid screw terminals
• Oversized voice coils with an impressive winding height for maximum electrical power handling and high linear excursion
• Large magnet systems for low Qts, ideal for compact bass-reflex enclosures
• Double-vented voice long-stroke coils for minimized compression effects
• Aluminum diecast basket with diamond cut surround mounting ring
• Solid screw terminals
Dimensions
Width
10.2 inch(es) / 25.91 cm
Height
10.2 inch(es) / 25.91 cm
