JL Audio Car Amplifiers 1-Channel HD1200/1

Store Only
JL AudioSKU: HD1200/1
The most power amplifier ever employs JL Audio's advanced Single-Cycle Control switching design and R.I.P.S. technology to deliver 1200 W... The most power amplifier ever employs JL Audio's advanced Single-Cycle Control switching design and R.I.P.S. technology to deliver 1200 W of clean power into any impedance between 1.5 and 4 ohm, giving you the highest degree of flexibility in designing your subwoofer system. Tight power supply regulation keeps distortion down and maximizes your bass quality. From a pure sound quality perspective, we invite you to compare the real-world, in-car performance of this amplifier to any other amplifier on the market, of any type, at any price. While targeted primarily to subwoofer applications, the HD1200/1 is a wide-range amplifier and can also be used to drive high-performance mid-range speaker systems. This amplifier features a brushed aluminum finish with black powder-coated cast alloy heat sinks and bottom panel. A black powder-coated, gasketed cover is also provided to protect the controls View more
Price:
$2,149.95
Specifications Documents
Specifications
General
Total Max Power
1200 W
Number of Channels
1
Amplifier Class
D
Load Impedance Capability
4 ohms
4 ohm Output Power
1200 W
2 ohm Output Power
1200 W
Crossover Frequencies
12 dB or 24 dB
Frequency Response
6 Hz - 8 kHz (+0, -1dB)
Total Harmonic Distortion
<0.03% @ 4 ohm/>500 / 50 Hz
Inputs/Outputs
RCA Inputs
Yes
RCA Outputs
Yes
Speaker Level Inputs
Yes
Subsonic Filter
Yes
Cut-Off Frequency (Subsonic Filter)
30 Hz
Dimensions
Width
10.75 inch(es) / 27.3 cm
Height
1.93 inch(es) / 4.9 cm
Depth
8.31 inch(es) / 21.1 cm
Shipping Dimensions
Weight
6.59 lb(s) / 2.99 kg
Warranty
Warranty
1 Year
UPC
UPC#
699440982504
Documents
Owners Manual
