Specifications
General
Power
• 75 watts RMS x 4 + 250 watts RMS x 1 at 4 ohms
• 100 watts RMS x 4 + 500 watts RMS at 2 ohms
• 200 watts RMS x 2 bridged at 4 ohms (4-ohm stable in bridged mode) + 500 watts RMS at 2 ohms
• 100 watts RMS x 4 + 500 watts RMS at 2 ohms
• 200 watts RMS x 2 bridged at 4 ohms (4-ohm stable in bridged mode) + 500 watts RMS at 2 ohms
Number of Channels
5
Amplifier Class
D
Load Impedance Capability
2 ohms
Crossover Frequencies
• Low-Pass Frequency: 50 Hz - 500 Hz
• High-Pass Frequency: 50 Hz - 500 Hz
• High-Pass Frequency: 50 Hz - 500 Hz
Total Harmonic Distortion
<1%
Additional Information
• Remote Level Control Port (for RBC-1, sold separately)
• Bridging switches for front and rear channel pairs
• 2/4/6 channel input switch
• Bridging switches for front and rear channel pairs
• 2/4/6 channel input switch
Inputs/Outputs
RCA Inputs
Yes
Dimensions
Width
14.69 inch(es) / 37.31 cm
Height
2.19 inch(es) / 5.56 cm
Depth
7 inch(es) / 17.78 cm
