Specifications
General
Maximum Power
600 W
RMS Power
300 W
Sensitivity
82.1 dB
Frequency Response
24 - 200 Hz
Impedance
4 ohms
Mounting Diameter
9.57 inch(es) / 24.31 cm
Mounting Depth
3.25 inch(es) / 8.26 cm
Features
Additional Information
• No pole vent: permits mounting close to rear wall of enclosure.
• Very small sealed enclosure volume requirements.
• Very long linear excursion capability (0.60 In / 15.2 mm, one-way).
• DMA-optimized motor designs.
• Patented "concentric tube" architecture.
• Patented "floating cone attach method" technology.
• Cast alloy frame.
• Injection molded, mica-filled polypropylene cone.
• Rubber surround.
• Aluminum-alloy dust cap and rear cap with JL Audio logo.
• Very small sealed enclosure volume requirements.
• Very long linear excursion capability (0.60 In / 15.2 mm, one-way).
• DMA-optimized motor designs.
• Patented "concentric tube" architecture.
• Patented "floating cone attach method" technology.
• Cast alloy frame.
• Injection molded, mica-filled polypropylene cone.
• Rubber surround.
• Aluminum-alloy dust cap and rear cap with JL Audio logo.
Warranty
Warranty
1 Year
Documents
