Features
Cone and Dust Cap
Vacuum-formed, mineral-filled polypropylene material offers excellent damping and low mass. The cone body features a gentle curvilinear profile to optimize response. A specially shaped dust cap attaches to the cone body and the voice coil former to improve high frequency behavior.
Suspension design
he moving assembly is suspended and damped via a large-diameter, linear profile spider formed from a Nomex®/polycotton blend, and a positive-roll, rubber surround. The two combine to provide optimum damping without prematurely restricting the C7-650cw's outstanding excursion capability.
Motor Design
The C7-650cw employs a high-density magnetic circuit with a high-grade Y35 Strontium-ferrite magnet, and a specially machined, T-Yoke motor topology. Motor magnetics have been precisely optimized utilizing advanced FEA tools to reduce distortion and provide linear motor force throughout the driver's performance range.
Specifications
General
Maximum Power
225 W
RMS Power
125 W
Frequency Response
50 Hz - 5,000 Hz
Impedance
4 ohms
Components
Yes
Mounting Diameter
5.56 inch(es) / 14.12 cm
Mounting Depth
2.77 inch(es) / 7.04 cm
Dimensions
Width
6.5 inch(es) / 16.51 cm
Height
6.5 inch(es) / 16.51 cm
Depth
3.65 inch(es) / 9.27 cm
