Specifications
General
Power
600 W
Peak Power
1200 W
Frequency Response
22-200 Hz Hz
Finish
Dark gray carpet with black insert
Additional Information
Dual Voice Coils: Due to the 10W6v3-D4's dual 4 ohm voice coils, the subwoofer can be configured as a 2-ohm (voice coils wired in parallel) or 8-ohm (voice coils wired in series) driver. The included jumper wires allow easy adjustment from one configuration to the other (the factory jumper position is 2-ohm).
Dynamic Motor Analysis (DMA): DMA is JL Audio's proprietary method of improving dynamic motor behavior. As a result of DMA optimization, the 10W6v3-D4 motor remains linear over a long excursion range, and also maintains a stable fixed magnetic field in the gap over a wide power range. The result is reduced distortion, faithfully reproduced transients, and tight, clean, articulate bass.
Subwoofer
Number of Woofers
1
Size
10 in
Impedance
4 ohms
Driver
W6v3
Model
10W6v3-D4
Dimensions
Width
12.13 inch(es) / 30.80 cm
Height
14 inch(es) / 35.56 cm
Depth
21.75 inch(es) / 55.25 cm
Weight
51.28 lb(s) / 23.26 kg
Warranty
Warranty
2 years parts and labor
