Specifications
General
RMS Power
1000 W
Number of Channels
1
Amplifier Class
D
Load Impedance Capability
2 ohms
Power at 4 ohm
600 W
Power at 2 ohm
1000 W
Frequency Response
7 Hz - 500 Hz
Total Harmonic Distortion
<1%
Additional Information
• With the addition of an HD-RLC remote level control (sold separately), the amplifier's subwoofer output level or master volume for all channels can be directly controlled from the helm
• The M1000/1v2 features the v2 Spec feature set, which consists of automatic turn-on capability (via signal sensing or DC-offset sensing), and a dual-range differential-balanced input section able to handle a wide range of input voltage levels
• This amplifier also features white and gray powder-coat finish, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment.
• The M1000/1v2 features the v2 Spec feature set, which consists of automatic turn-on capability (via signal sensing or DC-offset sensing), and a dual-range differential-balanced input section able to handle a wide range of input voltage levels
• This amplifier also features white and gray powder-coat finish, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment.
Inputs/Outputs
RCA Inputs
Yes
RCA Outputs
Yes
Highpass
No
Lowpass
Yes
Subsonic Filter
Yes
Cut-Off Frequency (Subsonic Filter)
30 Hz
Dimensions
Width
14.73 inch(es) / 37.41 cm
Height
2.05 inch(es) / 5.21 cm
Depth
7.09 inch(es) / 18.01 cm
