Specifications
General
RMS Power
600 W
Number of Channels
6
Amplifier Class
D
Load Impedance Capability
2 ohms
Power at 4 ohm
450 W
Power at 2 ohm
600 W
Frequency Response
12 Hz - 22,000 Hz
Total Harmonic Distortion
<1%
Additional Information
• This marine amplifier features white and gray powder-coat finishes, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment
• This amplifier is designed for operation in vessels with 24 volt, negative-ground electrical systems. Use of this product in vessels with positive ground and/or voltages other than 24 V may result in damage to the product and will void the warranty.
• This amplifier is designed for operation in vessels with 24 volt, negative-ground electrical systems. Use of this product in vessels with positive ground and/or voltages other than 24 V may result in damage to the product and will void the warranty.
Inputs/Outputs
RCA Inputs
Yes
RCA Outputs
Yes
Highpass
Yes
Lowpass
Yes
Dimensions
Width
10.23 inch(es) / 25.98 cm
Height
2.05 inch(es) / 5.21 cm
Depth
7.09 inch(es) / 18.01 cm
Shipping Dimensions
Weight
5.8 lb(s) / 2.63 kg
