Specifications
General
RMS Power
800 W
Number of Channels
8
Amplifier Class
D
Load Impedance Capability
2 ohms
Power at 4 ohm
600 W
Power at 2 ohm
800 W
Frequency Response
12 Hz - 22,000 Hz
Total Harmonic Distortion
1%
Additional Information
• The M800/8-24V includes a 12 dB / octave filter for each channel bank, which can be configured as a low-pass or high-pass filter and offers continuously variable cutoff frequency selection from 50-500 Hz
• With the addition of an HD-RLC remote level control (sold separately), you have the ability to control the level of two, four, six, or all eight of the amplifier's channel levels from the driver's seat
• This marine amplifier features white and gray powder-coat finishes, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment
• This amplifier is designed for operation in vessels with 24 volt, negative-ground electrical systems. Use of this product in vessels with positive ground and/or voltages other than 24 V may result in damage to the product and will void the warranty
• With the addition of an HD-RLC remote level control (sold separately), you have the ability to control the level of two, four, six, or all eight of the amplifier's channel levels from the driver's seat
• This marine amplifier features white and gray powder-coat finishes, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment
• This amplifier is designed for operation in vessels with 24 volt, negative-ground electrical systems. Use of this product in vessels with positive ground and/or voltages other than 24 V may result in damage to the product and will void the warranty
Inputs/Outputs
RCA Inputs
Yes
RCA Outputs
No
Dimensions
Width
14.72 inch(es) / 37.4 cm
Height
2.05 inch(es) / 5.2 cm
Depth
7.09 inch(es) / 18.0 cm
Warranty
Warranty
1 Year
