Features
Weblink - Your Portal to Waze, YouTube, and More
WebLink is the new way to get the most out of your in-car receiver. Download the KENWOOD WebLink app and you can connect your smartphone wirelessly or with USB to access some of your favorite apps such as Waze, Youtube, and Yelp. Using your apps through the large and clear touchscreen makes WebLink the safest and easiest way to use your smartphone on the road.
Pandora/Spotify Ready so You Can Stream Your Favorite Songs from Your Smartphone
Ability to control Pandora and Spotify from your iPhone via USB/Bluetooth or from your Android via Bluetooth to enjoy millions of songs you like.
Dual Phone Connection Allows You to Operate up to Two Phones Hands-Free
Allows two phones to be connected for hands-free operation at any time. Easily switch between both phones for incoming call. Also includes wide-band hands-free profile ver.1.6 for high quality clear calling.
Operate the Receiver from Your Smartphone with the KENWOOD Remote App
A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).
Clear Resistive Touch Panel
An advanced display panel with high contrast ratio, provides a brighter and clearer visual experience with vivid easy to read text.
Playable in Various Audio File Formats
Compatible with a broad range of audio file formats from high-resolution audio sources such as FLAC and WAV, to MP3, WMA and AAC. Also plays DSD (Direct Stream Digital) format les with a broader reproduction frequency band for life-like high-resolution sound reproduction. DSD playback up to 11.2 MHz ensures the very highest sound quality, with both the outstanding clarity of digital sound, coupled with the characteristic smoothness of analog sound sources.
Optimal Sound Performance with 13 Band Graphic EQ and Time Alignment
Use the graphic equalizer to tailor the sound quality to your unique tastes. Additional sound staging is available with the Time Alignment feature, designed to provide optimal sound performance.
Monitor the Front and Back Thanks to Dual Camera Input
Two Camera inputs for Front and Rear cameras. Parking guidelines appear on any standard backup camera image, making parking safer and easier.
Enjoy the Many Infotainment Features Available on the iDatalink Maestro RR
When an Automotive Data Solutions iDatalink Maestro RR is connected to a compatible KENWOOD receiver, it provides a seamless interface with factory infotainment features such as Satellite Radio, USB Media Player, Bluetooth hands-free and music streaming. Vehicle information such as HVAC, performance information, and TPMS can also be displayed.
Specifications
General
Maximum Power
200
Screen Size
6.95 in
THD and Frequency
• Total harmonic distortion: 0.010%
• Frequency response: 20 Hz - 20,000 Hz
• Frequency response: 20 Hz - 20,000 Hz
Number of Channels
4
Din Connector
2
Rear View Camera Compatibility
Compatible
Volume Control
Button Press
Compatibility
Satellite Radio
Yes
Pandora
Yes
Direct Control for iPod®/iPhone®
Yes
Bluetooth
Yes
Features
Video Playback
Yes
Remote Control
No
Motorized LCD Screen
No
Touchscreen
Yes
Additional Information
• 2 RCA Video Input for Front and Rear-View Camera
• Waze, YouTube, Yelp and Next Radio Ready through Weblink
• Audio decoder: Linear PCM, Dolby Audio, MP3, WMA, AAC(.m4a), WAV
• Video decoder: MPEG1, MPEG2, WMV, H.264, MKV
• DVD-Video, VIDEO-CD, CD-DA
• Waze, YouTube, Yelp and Next Radio Ready through Weblink
• Audio decoder: Linear PCM, Dolby Audio, MP3, WMA, AAC(.m4a), WAV
• Video decoder: MPEG1, MPEG2, WMV, H.264, MKV
• DVD-Video, VIDEO-CD, CD-DA
Inputs/Outputs
Front Speaker Pre-Outs
Yes
Back Speakers Pre-Outs
Yes
Pre-Outs Voltage
5 V
Pre-Out(s)
3 Preouts
Auxiliary Input
Yes
USB Input
No
Accessories
Included
• Sleeve
• Trimplate
• Trimplate
Shipping Dimensions
Weight
5.95 lb(s) / 2.7 kg
