Specifications
Cartridge
Type
Moving Magnet
Removable Stylus
Yes
Stylus Description
Stylus tip radius: r/R 8/40 µm
Output Voltage
5 mV
Tracking Force
1,4-1,7g (14-17 mN)
Frequency Response
20 Hz - 20,000 Hz
Stylus Shape
Elliptical
Recommended Impedance
1200 ohms
Additional Information
• Cartridge colour, body/stylus: Black/Bronze
• The cartridge body used for the 2M Bronze is manufactured from a newly-developed Lexan DMX Piano Black, a revolutionary material which ensures high rigidity while eliminating unwanted resonances
• The cartridge body used for the 2M Bronze is manufactured from a newly-developed Lexan DMX Piano Black, a revolutionary material which ensures high rigidity while eliminating unwanted resonances
Accessories
Included
• 1 x Stylus brush
• 1 x Screwdriver
• 2 x Screw M2,5 x 5
• 2 x Screw M2,5 x 7
• 1 x Stylus pressure gauge
• 1 x Screwdriver
• 2 x Screw M2,5 x 5
• 2 x Screw M2,5 x 7
• 1 x Stylus pressure gauge
Dimensions
Weight
0.007 g
