Specifications
General
Type
Indoors
Color
Glossy Black
Front Speakers
Power Handling
50 W
Frequency Response
125 Hz - 20,000 Hz
Crossover
Yes
Impedance
8 ohms
Driver High Frequency
25-mm (1 in) S-PAL™ dome, ferro-fluid damped and cooled
Driver Mid Range
102-mm (4 in) mineral-filled polypropylene cone; 25-mm (1 in) high-temperature voice coil; Advanced motor structures and oversized ferrite magnets
Width
4.8 inch(es) / 12.2 cm
Height
8.35 inch(es) / 21.2 cm
Depth
6.18 inch(es) / 15.7 cm
Weight
3.97 lb(s) / 1.8 kg
Brand/Model Specific Features
Suitable amplifier power range: 15-100 watts
Center Speaker
Power Handling
50 W
Frequency Response
125 Hz - 20,000 Hz
Crossover
Yes
Impedance
8 ohms
Driver High Frequency
25-mm (1 in) S-PAL™ dome, ferro-fluid damped and cooled
Driver Mid Range
102-mm (4 in) mineral-filled polypropylene cone; 25-mm (1 in) high-temperature voice coil; Advanced motor structures and oversized ferrite magnets
Width
4.8 inch(es) / 12.2 cm
Height
8.35 inch(es) / 21.2 cm
Depth
6.18 inch(es) / 15.7 cm
Weight
3.97 lb(s) / 1.8 kg
Brand/Model Specific Features
Suitable Amplifier Power Range : 15-100 watts
Rear Speakers
Power Handling
50 W
Frequency Response
125 Hz - 20,000 Hz
Crossover
Yes
Impedance
8 ohms
Driver High Frequency
25-mm (1 in) S-PAL™ dome, ferro-fluid damped and cooled
Driver Mid Range
102-mm (4 in) mineral-filled polypropylene cone; 25-mm (1 in) high-temperature voice coil; Advanced motor structures and oversized ferrite magnets
Width
4.8 inch(es) / 12.2 cm
Height
8.35 inch(es) / 21.2 cm
Depth
6.18 inch(es) / 15.7 cm
Weight
3.97 lb(s) / 1.8 kg
Brand/Model Specific Features
Suitable Amplifier Power Range : 15-100 watts
Subwoofer
Amplifier Type
High-current amplifier; Discrete output
Power
100 W
Drive Components
8 inches
Phase
Sub / Sat Phase Switch – 0° or 180°
Inputs
Analog Composite
Width
12.68 inch(es) / 32.2 cm
Height
13.46 inch(es) / 34.2 cm
Depth
12.68 inch(es) / 32.2 cm
Weight
21.38 lb(s) / 9.7 kg
Brand/Model Specific Features
Superior 8 in high-excursion driver made of a durable reinforced polymer composite that in concert with the superior suspension system and motor/magnet structure allow the cone to travel farther while maintaining effective control; Dual ported design for even and articulate response
Warranty
Warranty
5 Years
