Specifications
General
Speaker Type
Indoor
Color
Black
Frequency Response
Subwoofer cut-off frequency: variable 35 Hz - 150 Hz; Bypass Option
Number of Drivers
6
Features
Additional Information
Vibration-canceling design architecture; Patented built-in Ultra-Class-D™ power amplifier with Power Factor Correction; Sealed enclosure; PBK interface; Paradigm Perfect Bass kit included
Speakers
Bass Drivers
Six 254-mm (10 in) RCR™ mineral-filled co-polymer polypropylene cones; FEA-optimized overmolded thermoplastic foam-surrounds; 76-mm (3 in) ten-layer long-excursion voice coils; High-temperature composite Nomex® formers; Dual advanced spiders; 25.2-lb (10.5 kg) hard ferrite magnet / motor structure; Massive center heatsink and oversize pole piece; AVS™ die-cast heatsink chassis
Subwoofer
Amplifier Power
4500 W
Crossover
Yes
Stereo
Yes
Ported
No
Downfiring
No
Dimensions
Width
23.78 inch(es) / 60.4 cm
Height
24.49 inch(es) / 62.2 cm
Depth
22.76 inch(es) / 57.8 cm
Weight
106.0 kg (each)
Warranty
Warranty
3 years
UPC
UPC#
809918016710
