Specifications
General
Speaker Type
Indoor
Color
Black
Frequency Response
35 Hz - 150 Hz
Number of Drivers
1
Features
Additional Information
Subwoofer cut-off frequency (continuously variable 35 Hz – 150 Hz); Bypass option; Subwoofer level control; Sub/sat phase alignment (0° to 180); USB port/PBK interface; Auto On/Off
Speakers
Bass Drivers
254-mm (10 in) high-excursion mineral-filled co-polymer polypropylene cone with RCR™ resonance-control ribbing on underside; FEA-optimized overmolded, inverted Santoprene® surround; 38-mm (1-1/2 in) diameter split voice-coil construction (60-mm coil lengths); Dual Nomex® spiders; High-temperature Apical™ formers; Dual 12-mm-thick top plates; 10-lb (4.5 kg) triple ceramic (hard ferrite) magnet structure; AVS™ die-cast heatsink chassis
Subwoofer
Amplifier Power
850 W
Stereo
Yes
Ported
No
Downfiring
No
Dimensions
Width
11.73 inch(es) / 29.8 cm
Height
13.5 inch(es) / 34.3 cm
Depth
12.6 inch(es) / 32.0 cm
Weight
16.8 kg (each)
Warranty
Warranty
3 years
