Features
Packs a Punch
The 5-channel amplifier is rated at 2000 watts max with the A and B channels rated at 75 watts x 4 (RMS) and the subwoofer output rated at 600 watts at 2 (RMS). Compared to similarly priced multichannel amplifiers, the variable crossover networks on the GM-D9605 offer increased flexibility and give listeners more control. Block terminals for a cleaner installation and direct wire contact minimizing resistance.
Variable Low Pass Filter
For extra flexibility, a variable LPF makes audio frequency more adjustable according to subwoofer characteristics and personal listening preferences.
Turn Up the Bass
This car amplifier also features a Bass Boost Remote for optimal bass level adjustment according to listening preferences and music characteristics.
Speaker Level Inputs
What, you DON'T own a Pioneer headunit? Well, we won't hold it against you. In fact we'll even help you build onto your system. The GM-D9605's speaker level inputs allow simplify integration into existing aftermarket or factory installed (OEM) integrated entertainment systems so you can connect your OEM unit (or any unit that doesn't have the typical RCA-type inputs) without having to buy add-on adapters. So, the install goes faster, you save money, and you've got a Pioneer amp in your vehicle.
Specifications
General
Total Max Power
2000 W
Number of Channels
5
Amplifier Class
D
Load Impedance Capability
1 ohm
4 ohm Output Power
650 W
2 ohm Output Power
1000 W
Crossover Frequencies
40 Hz - 500 Hz
Frequency Response
10 Hz - 50,000 Hz
Total Harmonic Distortion
0.05
Inputs/Outputs
RCA Inputs
Yes
Speaker Level Inputs
Yes
Subsonic Filter
No
Dimensions
Width
12.4 inch(es) / 31.5 cm
Height
2 inch(es) / 5.08 cm
Depth
7.87 inch(es) / 19.99 cm
Warranty
Warranty
1 Year
UPC
UPC#
884938312752
